Twitter| Business Type | Manufacturer, Exporter, Supplier |
| Brand Name | SinFin |
| Usage/Application | Residential Use, Office Use |
| Nominal Cooling Capacity (Tonnage) | 2.5 Ton |
| Click to view more | |
Preferred Buyer From
| Location | India ( Andaman & Nicobar Islands, Andhra Pradesh, Jammu & Kashmir, Jharkhand, Karnataka, Kerala, Madhya Pradesh, Pondicherry, Rajasthan, Tamil Nadu, Telangana, Uttar Pradesh, West Bengal only) & All other countries |
Product Details
Condenser Type
Aluminium
Features
Energy Saver, 100% Copper, Fix And Lock, Self Diagnosis, Smart Ready, Comfort Sleep
Voltage
220V
Model Number
Sway AC -2.5E
Product Type
Split Inverter Air Conditioner
Remote Type
LCD Remote With Display
Series Name
Magic Cool Series
The inputting Airconditioner will be 230v from ac mains either from EB grid (or) from 5Kwp /96V solar off grid plant. The battery back up on power outage shall be 3 to 4 hrs . Solar off grid plant is optional on remote village locations where there is no Govt grid supply. This Airconditioner run from 230v single phase ac from grid supply ( Or) from the 230v ac output from solar off grid plant of 5 kw capacity.
Note: this Airconditioner can not be connected to solar panels directly.
Technical Specifications
| Specification Model | Model Sway 2.5 |
| Cooling Capacity BTU | 19500-26500 |
| Capacity (Ton) | 2.5 Ton |
| Starting Current Amp. | 0.7 |
| Running Current Amp. | Min 2.5 |
| Max 10 | |
| Air Flow | 580/980 |
| Refrigerant | R410/R32 |
| Per Hour Unit Consumption | 1.8/2.1 |
| Compressor Magnetic/Vibratic | Magnetic/Vibratic |
| Electricity Saving Comparison to other AC | Upto 80% |
| Power Input | 190V-250V AC |
| Sound Level (H/M/L) | 38/34/31 |
| Indoor Unit Dimention | 1016x381x305mm |
| Net Weight | 15kgs |
| Outdoor Unit Dimentions | 915x432x635 mm |
| New Weight | 38 kgs |
| Noise Level | 36 dBA |
| Power Source Rating MCB | 6A |
| Power Supply to Ref. Max Piping Length | Indoor |
| 15 Ft. |
