Solar Power Plants

Solar power plants-We supply and install solar roof top power plants of capacities upto100kw that have following types rn1)solar on grid ( grid connected ) plant connected with 2 way net metering - both solar power and AC power (called as reference power) together balance the load and if load demand more than that of solar generation then ac power with be drawn to keep the load (electrical appliances) in working condition if load demand is less then excess solar power generated exported to Govt grid to obtain tariff benefits on the EB bill disadvantage is that the inverter will not function & generate solar power when reference EB mains fails 2) solar off grid power plant has battery bank for power back up in the night time. The solar energy stored in the battery bank via MPPT solar charger inside solar inverter during day time and that can be used to power the appliances and utilities in night rn3) solar on grid hybrid plant is nothing but combination of solar off grid and solar on grid power plant . In this case the battery will get charged from excess power from solar as well from ac source like in on-grid plant and excess solar energy exported to Govt grid via net meter . During power outage the solar inverter continue to run to charge the battery bank and during no mains no solar the battery bank will feed dc supply to the inverter and output of the same will balance critical loads only

We offer a wide range of Solar Power Plants that finds wide application in different sectors. Harness the Power of Solar Switch on to Solar Electric to run your electrical gadgets or pumps 24 X 7 hassles Free.

Features:

• We have the capability to offer Solar Power Projects on a turnkey basis comprising supply, Installation & Commissioning anywhere in India


• We provide our clients (Companies, Promoters, Builders) Solar Power Plant -complete package (Standalone/Dual) up to 30KW t with expertise backed


• We take care of the Operation & Maintenance of the solar plants post commissioning


• Our Solar PV modules are as per MNRE/IES standards, guaranteed life for minimum 20 years for 100% efficiency


• The Batteries are of EXIDE Tubular, specially made for Solar Application with longer life & carries more warranty than conventional


• The electronics for Inversion from DC to AC are guaranteed for 2 years tailor made as per international specification


• We assist our clients to get bank loan & Govt. Subsidy @ Rs 81 per watt to get their ROI quickly plus clients can avail IT benefits for 5 years

Technical Specifications:

• Solar Inverter (Dual System -Grid & Solar with MPPT) - Three Phase Input & output


• System capacity Range :8KW (10 KVA) to 30KW (40 KVA) & System Voltage :upto 360V


• Plant Output details:415 AC Three Phase, 50Hz ( /- 3Hz) Peak efficiency:95% on normal sunny days


• Solar Array Spec.:Input 100V DC to 440V DC and MPPT (Charge controller) Voltage 110 - 396V Solar PV panels are as per MNRE spec.


• Solar Tubular Battery: 120V DC to 360V DC Voltage , Current - 74A to 185 A We use normally Exide Monoblock deep cycle Solar Tubular Battery


• Grid tracking voltage:414 V Three phase, ( /-10%) , 50Hz ( /-3 Hz)


• Environmental:Operating.Temp - 0 to 40Deg C, Humidity-95%RH (Non-Condensing), Noise-

We offer a wide range of Solar Power Plant Projects that finds wide application in different sectors. Harness the Power of Solar Switch on to Solar Electric to run your electrical gadgets or pumps 24 X 7 hassles Free.

Features:

• We have the capability to offer Solar Power Projects on a turnkey basis comprising supply, Installation & Commissioning anywhere in India
• We provide our clients (Companies, Promoters, Builders) Solar Power Plant -complete package (Standalone/Dual) up to 30KW t with expertise backed
• We take care of the Operation & Maintenance of the solar plants post commissioning
• Our Solar PV modules are as per MNRE/IES standards, guaranteed life for minimum 20 years for 100% efficiency
• The Batteries are of EXIDE Tubular, specially made for Solar Application with longer life & carries more warranty than conventional
• The electronics for Inversion from DC to AC are guaranteed for 2 years tailor made as per international specification
• We assist our clients to get bank loan & Govt. Subsidy @ Rs 81 per watt to get their ROI quickly plus clients can avail IT benefits for 5 years

Technical Specifications:

• Solar Inverter (Dual System -Grid & Solar with MPPT) - Three Phase Input & output
• System capacity Range :8KW (10 KVA) to 30KW (40 KVA) & System Voltage :upto 360V
• Plant Output details:415 AC Three Phase, 50Hz ( /- 3Hz) Peak efficiency:95% on normal sunny days
• Solar Array Spec.:Input 100V DC to 440V DC and MPPT (Charge controller) Voltage 110 - 396V Solar PV panels are as per MNRE spec.
• Solar Tubular Battery: 120V DC to 360V DC Voltage , Current - 74A to 185 A We use normally Exide Monoblock deep cycle Solar Tubular Battery
• Grid tracking voltage:414 V Three phase, ( /-10%) , 50Hz ( /-3 Hz)
• Environmental:Operating.Temp - 0 to 40Deg C, Humidity-95%RH (Non-Condensing), Noise-
